Hàng hiệu: | Norgren |
Chứng nhận: | CE |
Số mô hình: | B72G-3AK-QD3-RMN |
Tài liệu: | en_8_160_300_B72G.pdf |
Minimum Order Quantity: | 1 |
---|---|
Giá bán: | Có thể đàm phán |
Packaging Details: | Carton /As The Clients Require |
Delivery Time: | 1-7Work Days After Payment |
Điều khoản thanh toán: | T/T, Liên minh phương Tây, PayPal |
Supply Ability: | 5000PCs Per Month |
Trung bình: | Không khí nén | Loại thoát nước: | Tự động xả |
---|---|---|---|
Điều chỉnh áp suất đầu ra: | 0,3 ... 10 thanh, 4 ... 145 psi | Kích thước cổng: | G3/8 |
Phạm vi: | B72G | Vật liệu bát: | Polycarbonate |
Làm nổi bật: | Norgren Excelon filter regulator,Pneumatic filter regulator G3/8,Excelon FRL unit PTF |
Medium | Compressed air |
---|---|
Operating Temperature | -34 ... 65 °C, -29 ... 149 °F |
Port Size | 3/8 PTF |
Drain Type | Manual |
Gauge Port | 1/8 PTF |
Filter Element | 40 μm |
Adjustment | Knob |
Maximum Inlet Pressure | 10 bar, 145 psi |
Outlet Pressure Adjustment | 0.3 ... 10 bar, 4 ... 145 psi |
Relieving / Non Relieving | Relieving |
Flow | 38 dm3/sec, 81 scfm |
Materials - Adjusting Knob | Acetal |
Materials - Body | Zinc alloy |
The NORGREN F18 series filters are specially designed for compressed air and neutral gases to effectively remove liquid water and solid impurities. Its key features and details include:
Efficient water removal and impurity filtration: This filter can efficiently and finely filter out impurities in the liquid and gas being processed, ensuring clean operation without noise.
Automatic drainage function: It is equipped with an automatic drain and has connection ports with 1/8-27 and 1/8-28 male pipe threads. Please note that the inner diameter of the flexible pipe connecting the drain should not be less than 3/16 inch (about 5 millimeters), as it may otherwise impact the drain's normal operation.
Humanized observation design: Featuring a high visibility prism liquid level indicator lens, this design allows users to easily observe the liquid level within the filter cup and stay informed about drainage requirements.
Durable and sturdy material: The main components are constructed from an aluminum body, while the filter cup is made from a transparent nylon metal bowl, offering both convenience for observation and structural strength. The filter element is crafted from sintered bronze, and the sealing material is chloroprene/NET elastomer, ensuring product stability and durability over extended periods of use.
Reliable Filtering Performance: The NORGREN F18 series filters are known for their dependable filtering performance, making them suitable for various situations where clean compressed air is needed.
Widely Applicable Fields: NORGREN's products find applications in essential sectors such as factory automation, material handling, railways, energy, process control, and life sciences. While these fields may not explicitly mention the F18 series, they provide an idea of the potential range of applications for this product.
Core Function Assurance System: The primary function of the F18 series is to eliminate liquid water and solid impurities from compressed air or gas. This is critical for safeguarding downstream pneumatic equipment (such as cylinders, solenoid valves, etc.) and can significantly enhance the lifespan and reliability of the equipment and system.
The Product Technical Support and Services for the Pneumatic Filter Regulator Lubricator include:
- Installation assistance and guidance
- Troubleshooting support for any issues related to the product
- Maintenance tips and recommendations to ensure optimal performance
- Product training sessions for users and maintenance personnel
Product Name: Pneumatic Filter Regulator Lubricator
Description: This product is designed to regulate air pressure, filter contaminants, and provide lubrication for pneumatic systems.
Package Contents: - 1 Pneumatic Filter Regulator Lubricator - Mounting brackets and hardware - Instruction manual
Shipping Information: - Shipping Method: Standard Shipping - Estimated Delivery Time: 3-5 business days -
